Problem 11.5 - By Integration of Moment Equation

Problem Statement

A cantilever beam of length L = 6.5 ft is subjected to a distributed load w = 300 lb/in. and a concentrated load F = 2.5 kips as shown. Determine the magnitude of the deflection of the beam at point B. Assume EI = 45,000 kip-in.2.

A beam of length L is subjected to a distributed load w and a point load P at L/2. Point A is on the left of the beam, and point B is on the right end, a distance of L from A.

Figure 1: A simply supported beam is subjected to the loading shown.

[Problem adapted from © Kurt Gramoll CC BY NC-SA 4.0]
